| Sensor | 1/2.8" CMOS |
| Max. Image Resolution | 1920 x 1080 |
| Megapixels | 2MP |
| Minimum Illumination | 0.025 lux @ F2.0 (Color, 30 IRE) 0.0025 lux @ F2.0 (B/W, 30 IRE) 0 lux (Illuminator on |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Lens | 2.8mm |
| Day& Night | Auto (ICR)/Color/B/W |
| Wide Dynamic Range | DWDR |
| Video Compression | H.264B; H.264; H.264H; H.265 |
| Video bit Rate | Main stream: 1920 ? 1080@ (1–25/30 fps) Sub stream: 640 ? 480@(1–25 fps) 640 ? 480@(1–30 fps) |
| Frame Rate | Main stream: 1920 x 1080@ (1–25/30 fps) Sub stream: 640 x 480@(1–25 fps) 640 x 480@(1–30 fps) |
| Network Protocols | IPv4; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; DHCP; DNS; NTP; Multicast; RTMP |
| Working Temperature | ure –40 °C to +60 °C (–40 °F to +140 °F) |
| Power Consumption | Basic: 2 W (12 VDC); Max. (H.265+IR intensity): 4.9 W (12 VDC) |
| Dimensions (W x D x H) | Φ110.7 mm x 88.7 mm (Φ4.33" x 3.49") |
| Weight | 414 g (0.91 lb) |
| Horizontal Resolution | 1920 |
| S/N Ratio | >56 dB |
| Recognition | Face Detection |
| Alarm In/Out | N/A |
| Power Supply | 12 VDC |
| Bracket 1 | PFA136 Junction Mount |
| Bracket 2 | PFB203W Wall Mount |
| Bracket 3 | PFA109+PFB220C Ceiling Mount |
• DH-IPC-HDBW1230DE-SW-0280B / 10327_CAMIP2MP.291.pdf) (
, 555.23 kb)
